KROHNE OPTISWIRL 5080 Vortex Flow Meter
Vortex flowmeter for high temperature applications
- For liquids, gases and steam up to +427°C / +800°F
- Adaptive filtering and signal conditioning
- Flange: DN15…300 / ¾…12″, max. PN160 / ASME 1500 lb;
Sandwich version: max. DN200 / 8″ - 2-wire, 4…20 mA, HART®
Inquiry Form
We will get in touch with you shortly
Description
Description
Product features and options depend on device configuration:
- Patented, adaptive filtering and signal conditioning for increased low flow performance
- Flange or space-saving sandwich version
- Also available as dual version with two converters for multi-product pipelines and measurement redundancy
- Ex ia, Ex d approvals
General information
| Product type | Flowmeter |
| Product family name | OPTISWIRL |
| Product positioning | For high temperature applications |
| Measurement principle | Vortex |
| Measured media | Liquids, Gases, Steam |
Operating conditions
| Process pressure | max. 103.4 barg/ 1500 psig |
| Process temperature | +150…+427°C/ -302…+800°F |
Materials
| Measuring tube | Austenitic stainless steel (1.4404/316L), Nickel alloy (Grade CW2M), Austenitic stainless steel (304/304L) |
| Process connection | Austenitic stainless steel (1.4404/316L), Austenitic stainless steel (304/304L) |
Process connections
| Flange connections | EN (1092-1): DN15…300 ASME (B 16.5): ½…12″ JIS (B 2220): 15…300A |
| Other connections | Sandwich connection: EN (1092-1): DN15…200 ASME (B 16.5): ½…8″ |
Approvals/Standards
| Certificates/Approvals Others | NACE |
| Certificates/Approvals Ex | ATEX, IECEx |
Communication
| Analogue outputs | 4…20 mA |
| Discrete outputs | Pulse, Frequency |
| Digital outputs | HART® |
